Baoji Factory of Titanium Round Bar Titanium Alloy Rods Gr5

Product Description

Xi'an baoti Materials Co.,Ltd is leading titanium and titanium alloy supplier, manufacturer and distributor. We specialized in the sales of high quality titanium and its alloy products like tube, pipes, bar, rods, sheets, plates. Located in Baoji, the titanium valley of China, we manufactured and supplied titanium products with factory price and trustworthy quality.

Titanium and titanium alloy have been widely used in many challenging applications like Aerospace, Medical, Industrial, and Oil and Gas industries due to its unique combination of high strength, light weight, corrosion resistance, biocompatibility, and higher temperature performance. Our Titanium round bar meets numerous AMS, ASTM, NACE, EN, and MIL specifications and various grades available in Titanium CP Grade 1, Grade 2, Grade 4, Grade 5 6Al-4V, Grade 23 6Al-4V ELI, and 6Al-2Sn-4Zr-6Mo.

Baoji Factory of Titanium Round Bar Titanium Alloy Rods Gr5

	Specification	ASTM: ASTM B348, ASTM F67, ASTM F136, AMS: AMS 2631, AMS 4928, AMS 4930, AMS 4965, AMS 6930, AMS 6931, AMS 6932 MIL-T: MIL-T-9047
	Grades	Commercially Pure Titanium Grade 2 CP 3 \| UNS R50400 Grade 4 CP 1 \| UNS R50700 Titanium Alloys 6Al-4V Grade 5 \| UNS R56400 6Al-2SN-4ZR-2MO \| UNS R54620 6Al-4V Grade 5 STA \| UNS R56400 7Al-4Mo \| UNS R56740 6Al-4V ELI Grade 23 \| UNS R56407 Grade 7 \| UNS R52400 6Al-6V-2SN \| UNS R56620
	Size:	Round: 0.125" (3.175mm) to a 12" (304.8mm), L:6000mm
	Applications	Medical, Aerospace, Military, Medical. Petrochemical engineering, Metallurgy, eElectroplating, Vacuuming metalling, Sports goods and so on.
	Machining ability/Our services	CNC turning, CNC milling, Wire EDM machining, CNC grinding and more
	Quality control	100% critical inspection before packing Titanium bar is tested by our local authorized non-ferrous metal institution for its chemical and machnical compositions, ultrosonic test, granulations test, etc.
	Surface	Polish, Grounded, Peeled, etc.

Grades	UNS No	N	C	H	Fe	O	Al	V	Pd	Mo	Ni
GR 1	R50250	0.03	0.08	0.015	0.2	0.18
GR 2	R50400	0.03	0.08	0.015	0.3	0.25
GR 3	R50550	0.05	0.08	0.015	0.3	0.35
GR 4	R50700	0.05	0.08	0.015	0.5	0.4
GR 5	R56400	0.05	0.08	0.015	0.4	0.2	5.5-6.75	3.5-4.5
GR 7	R52400	0.03	0.08	0.015	0.3	0.25			0.12-0.25
GR 9	R56320	0.03	0.08	0.015	0.25	0.15	2.5-3.5	2.0-3.0
GR 12	R53400	0.03	0.08	0.015	0.3	0.25				0.2-0.4	0.6-0.9
GR 23	R56401	0.03	0.08	0.0125	0.25	0.13	5.5-6.5	3.5-4.5
