Nm360 Nm400 High Strength Wear Resistant Alloy Steel Plate

Product Description

Production Description:
1. Steel Grade:  NM360, NM400, NM450, NM500, NR360, NR400
2. Product name: NM360 NM400 High Strength Wear Resistant Alloy Steel Plate
3.Size: thickness: 1mm-500mm
            width: 1000-3000mm
            Length: 1000-12000mm
4.Heat Treatment: as required
5.Standard: ASTM,GB,JIS,DIN,BS

Typical Steel Grades/Specifications
Grades		Specifications		Size Range(width:mm)		Delivery Condition
NM360		GB/T 24186 Agreement		≤120		Q,Q+T
NM400				≤120
NM450				≤120
NM500				≤80
XCHD400				≤80
XCHD450				≤50
XCHD500				≤50


Chemical Composition:
Grades	Chemical Composition(wt%)
Grades	C	Si	Mn	P	S	Al	Cr+Ni+Mo	Nb+V+Ti
NM360	0.10-0.30	0.20-0.40	1.0-2.0	≤0.015	≤0.003	≥0.020	<0.6	Trade Amount
NM400	0.10-0.30	0.20-0.40	1.0-2.0	≤0.015	≤0.003	≥0.020	<0.9
NM450	0.10-0.40	0.20-0.40	1.0-2.0	≤0.015	≤0.003	≥0.020	<1.2
NM500	0.10-0.40	0.20-0.45	1.0-2.0	≤0.015	≤0.003	≥0.020	<1.5
XCHD400	0.10-0.30	0.20-0.40	1.0-2.0	≤0.015	≤0.003	≥0.020	<0.6
XCHD450	0.10-0.40	0.20-0.40	1.0-2.0	≤0.015	≤0.003	≥0.020	<0.9
XCHD500	0.10-0.40	0.20-0.45	1.0-2.0	≤0.015	≤0.003	≥0.020	<1.5

Mechanical Properties:
Grades	Size	Rel/ReH/Rp0.2,MPa	Rm,MPa	A50,%	AKV,ºC	AKV,J			HBW
NM360	20	1061	1313	17	20	169	164	162	398
NM400	100	1233	1377	15	-20	35	37	42	415
NM450	60	1345	1434	9.5	-20	72	59	58	445
NM500	50	1608	1706	10.5	-20	43	50	45	485
XCHD400	35	1125	1261	17.5	-40	52	45	40	393
XCHD450	30	1281	1400	10.5	-40	45	48	52	448
XCHD500	6	1465	1529	13.5	-40	24	24	22	495

Company Information

Bozhong Group Mainly supply in forms of coil, sheet, plate, rod, bar, tube, pipe, beam, angle, flange, wire, strip, channel, etc., with various varieties, wide range of dimensions, high purity, stable chemical composition, high dimensional accuracy and excellent surface quality. The products are mainly used in the fields of industries such as automobile engineering, railway transportation, aviation, aerospace, machinery, petrochemical, energy, environmental protection, offshore, chemical, oil & gas, ilitary, power plant, nuclear power, pressure vessel, boiler equipment, mold manufacture, etc.

steel coil
l steel plate
l steel sheet
l steel bar/rod
    steel round bar
    steel flat bar
    steel square bar
l steel pipe/tube ( welded or seamless )
    steel round pipes
    steel square pipes
    steel welded tubes
    steel seamless tubes
l steel strip
l steel beam
l steel angle
l steel channel
l steel flange
l Steel wire

Bozhong Group can supply a variety of structural steel, high-strength steel, wear-resistant steel plate, boiler and pressure vessel steel, marine engineering and stainless steel plate in the thick steel and various European standard bars and pipes and profiles.Our global sales and service network throughout all around the world to ensure that the goods reach the customer in the shortest time.

We can follow your drawings and requirements, to provide you with oxygen cutting, plasma cutting and laser cutting and other processing services. You can also perform ultrasonic testing in accordance with EN10160 standard, EN10164 standard test Z15, Z25, Z35, weld bending detection, PWHT detection,etc.

We have ISO9001: 2000 quality management system certification, and obtain the quality certification from all the well-known certification company, including TuV / LRS / GL / CE and so on.

Special steel includes as below:
Boiler and pressure vessel steel
Pipeline steel
Bridge steel
Nuclear power steel
Structural steel
Die steel
High strength steel
Abrasion resistant steel
Weathering, corrosion resistant and fire resistant steel
High rise building steel
Shipbuilding and offshore engineering steel
