En 10216 P355nl1 Hot Rolled Seamless Pipes
EN10216-3 Seamless Alloy Steel Tubes P355NEN 10216-3 Seamless steel tubes for pressure purposes: Alloy fine grain steel tubes, used in elevated pressure installations and where it is necessary to assure the appropriate level of impact resistance of steel in high temperatures.EN 10216-3 series specif......
Send Inquiry
Product Description
EN10216-3 Seamless Alloy Steel Tubes P355N
EN 10216-3 Seamless steel tubes for pressure purposes: Alloy fine grain steel tubes, used in elevated pressure installations and where it is necessary to assure the appropriate level of impact resistance of steel in high temperatures.
EN 10216-3 series specifications for order information, grades, delivery condition, scope of testing and marking. EN10216-3 Grade P355NH are reheated and furnished in full annlealed, is othermal annealed or normalised quenched and tempered condition. EN 10216-3 pipes are manufactured with TC1 tests (I requirement level) and TC2 (III requirement level).
Equivalent Designation: DIN 17179 Grade FGP 36
Outside diameter:21.3-660 mm
Wall thickness: 2.0- 100 mm
Length: up to 12m -0/+15%
Straightness: < 0.0015 of pipe length
P355N series Chemical Composition: (% max)
Grades | C | Si | Mn | P | S | Cr | Mo | Ni | Cu | Nb |
P355N | 0.20 | 0.50 | 0.90-1.70 | 0,025 | 0,020 | 0,30 | 0,08 | 0,50 | 0,30 | 0,020 |
P355NH | ||||||||||
P355NL1 | 0.18 | |||||||||
P355NL2 | 0 |
P355N series Mechanical properties, in room temperature, in Thermal processing stage +N:
Grades | Upper yield limit or yield strength Re or Rp0,2 min for wall thickness T in mm | Tensile strength Rm for wall thickness T in mm | Elongation A% min | ||||||||
≤20 | 20-40 | 40-50 | 50-65 | 65-80 | 80-100 | ≤20 | 20-65 | 65-100 | 1 | t | |
P355N | 355 | 345 | 335 | 325 | 315 | 305 | 490- 650 | 450- 590 | 450- 590 | 22 | 20 |
P355NH | |||||||||||
P355NL1 | |||||||||||
P355NL2 | |||||||||||
As a Chromemoly Tube supplier, KINGMETAL provides EN 10216-3 grade P355N seamless alloy steel tubes used in power engineering and other associated fields of industry. If you are looking EN 10216-3 chromly tubing
