China En 10204 Precipitation Hardening Fv520b Stainless Steel Plate

Product Description

1.Specification:

En 10204 Precipitation Hardening Fv520b Stainless Steel Plate

Product Details
Product name	EN 10204 Precipitation Hardening FV520B Stainless Steel Plate
Brand name	ABOOM
Standard	ASTM A312, ASTM A554, ASTM A790, EN10216-5, EN10217-7, JIS G3468, JIS G3459
Material	304, 316L, 321, 310S, 1.4301, 1.4307, 1.4404, S31803, S32750, 904L, Monel 400, Inconel 800,Incoloy926
Surface	Pickling, 400grit polishing, 600grit polishing, mirror finish
Certificate	BV, LR, GL, NK, RMRS
Packing	In bundles with waterproof material, in wooden cases
Shipment	By sea, by air, by express

Application area:

Large centrifugal compressor / Fan system

FV520b is a new type of martensitic precipitation hardening acid and heat-resistant stainless steel developed on the basis of the original FV520. The type steel precipitates ε - Cu, NBC, Mo2C, M7C3 and M23C6 in the aging process through strengthening elements such as Cu, Nb and Mo, which plays the largest strengthening effect

3/16"	1/4"	5/16"	3/8"	7/16"	1/2"	9/16"	5/8"	3/4"	7/8"	1"
4.8mm	6.3mm	7.9mm	9.5mm	11.1mm	12.7mm	14.3mm	15.9mm	19mm	22.2mm	25.4mm

1 1/8"	1 1/4"	1 1/2"	1 3/4"	2"	2 1/4"	2 1/2"	2 3/4"	3"	3 1/2"	4"
28.6mm	31.8mm	38.1mm	44.5mm	50.8mm	57.2mm	63.5mm	69.9mm	76.2mm	88.9mm	101.6mm

FV520B Precipitation Hardening Stainless Steel Plate

The mechanical properties of FV520B steel such as strength, plasticity and toughness are particularly sensitive to the heat treatment process. The microstructure of FV520B stainless steel before and after solution treatment + adjustment + aging heat treatment is found.
After heat treatment, the lath martensite structure of FV520B steel is fine and uniform, which increases the number of grains, increases the grain boundary area, and the second phase particles uniformly distributed in the matrix, so that the solution + adjustment + aging treatment FV520B The tensile resistance and fatigue resistance of steel have been significantly improved

The strength of fv520b steel reaches the maximum value at 1050 ºC solution treatment + 850 ºC intermediate treatment + 470 ºC aging.

2.

Chemical Composition(%)
Grade	C	Si	Mn	P	S	Cr	Ni	Mo	N	Cu
201	≤0.15	≤0.75	5.5~7.5	≤0.060	≤0.03	16.00~18.00	3.5~5.5	-	-	0.08	1.5
202	≤0.15	≤1.00	7.5~10.00	≤0.060	≤0.03	17.00~19.00	4.0~6.0	-	≤0.25
301	≤0.15	≤1.00	≤2.00	≤0.045	≤0.03	16.00~18.00	6.00~8.00	-
302	≤0.15	≤1.00	≤2.00	≤0.035	≤0.03	17.00~19.00	8.00~10.00	-
304	≤0.07	≤1.00	≤2.00	≤0.045	≤0.03	18.00~20.00	8.00~10.50	-
304L	≤0.030	≤1.00	≤2.00	≤0.045	≤0.03	18.00~20.00	9.00~13.00	-
310S	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	24.00~26.00	19.00~22.00	-
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	16.00~18.00	10.00~14.00	2.00~3.00
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	16.00~18.00	12.00~15.00	2.00~3.00
321	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	17.00~19.00	9.00~13.00	-
430	≤0.12	≤0.75	≤1.00	≤0.040	≤0.03	16.00~18.00		-
2205	≤0.03	≤1.00	≤2.00	≤0.030	≤0.015	22.00~23.00	4.5~6.5	2.5~3.5
2507	≤0.03	≤0.08	≤1.20	≤0.035	≤0.015	24.00~26.00	6.00~8.00	3.0~5.0
904L	≤0.02	≤1.00	≤2.00	≤0.045	≤0.035	19.00~23.00	23.00~28.00	4.0~5.0		1.0~2.0
INCONEL 028	≤0.03	≤1.00	≤2.50	≤0.030	≤0.030	≤28.0	≤34.0	≤4.0		≤1.4
MONEL 400	≤0.30	≤0.5	≤2.00	-	≤0.024	-	≥63.0	-		≤34.0
INCONEL 800	≤0.10	≤1.00	≤1.50	-	≤0.015	≤23.0	≤35	4.0~5.0	-	≤0.75	Ti≤0.6 Al≤0.6

Packaging & Shipping

Packaging Detail	Inside:Packed with plastic protective film to protect each piece Outside:Wrap to be bundles by waterproof craft paper
Delivery Time	30 days

-- FAQ --

Q1:Are you factory or trading company?
A:We are professional manufacturer .

Q2:What are the advantages of your company?
A: We have many professional technical personnel.And we have more competitive prices and better after-sales service than trading companies.

Q3:How do you control the quality?
A:Our company is certificated to ISO9001:2008.We have many inspectors and every product will have been tested for 4-5 processes.
We welcome customers or the third party inspection agencies to come to our factory for inspection.

Q4:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis
of the quality assurance.Usually the delivery time is within 7-15 days after we recieved your desipot.
