China Incoloy 330 Incoloy Alloy Seamless Pipe Uns N08830 High Temperature Resistance

Product Description

1.Specification:

Product Details
Product name	NS1101 / N08800 Incoloy Alloy Corrosion Resistant Alloy Seamless Pipe Incoloy 800
Brand name	ABOOM
Standard	ASTM A312, ASTM A554, ASTM A790, EN10216-5, EN10217-7, JIS G3468, JIS G3459
Material	N08367 Al-6XN 1.4501 Incoloy25-6hn NAS 255NM
Surface	Pickling, 400grit polishing, 600grit polishing, mirror finish
Certificate	BV, LR, GL, NK, RMRS
Packing	In bundles with waterproof material, in wooden cases
Shipment	By sea, by air, by express

Material designation: Incoloy 330 nickel based alloy
US grade: N08830

Incoloy 330 (N08830) nickel based alloy overview:

Incoloy 330 (N08330) is a nickel-iron-chromium austenitic alloy specifically designed to resist oxidation and carburizing in high temperature environments. The 34% -37% nickel content makes the material highly resistant to chloride stress corrosion cracking and sigma phase precipitation embrittlement. The material is machined through standard machining procedures for stainless steel and nickel alloys. It is widely used for corrosion resistance under the environment of cyclic heating and carburizing.

Chemical composition of Incoloy 330 (N08830) nickel based alloy: see Table-1:

Table-1 %

C≤	Si≤	Mn≤	P≤	S≤	Cr≥	Ni≥	Mo≥	Cu≤
0.08	0.75-1.50	2.00	0.030	0.030	17.0-20.0	34.0-37.0	1.0-1.75	1.00
other	Sn≤	Pb≤	Ti≤	Fe≤	Co≤	V≤	W≤	Nb≤
other	0.025	0.005	-	-	-	-	-	-

2.

Chemical Composition(%)
Grade	C	Si	Mn	P	S	Cr	Ni	Mo	N	Cu
201	≤0.15	≤0.75	5.5~7.5	≤0.060	≤0.03	16.00~18.00	3.5~5.5	-	-	0.08	1.5
202	≤0.15	≤1.00	7.5~10.00	≤0.060	≤0.03	17.00~19.00	4.0~6.0	-	≤0.25
301	≤0.15	≤1.00	≤2.00	≤0.045	≤0.03	16.00~18.00	6.00~8.00	-
302	≤0.15	≤1.00	≤2.00	≤0.035	≤0.03	17.00~19.00	8.00~10.00	-
304	≤0.07	≤1.00	≤2.00	≤0.045	≤0.03	18.00~20.00	8.00~10.50	-
304L	≤0.030	≤1.00	≤2.00	≤0.045	≤0.03	18.00~20.00	9.00~13.00	-
310S	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	24.00~26.00	19.00~22.00	-
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	16.00~18.00	10.00~14.00	2.00~3.00
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	16.00~18.00	12.00~15.00	2.00~3.00
321	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	17.00~19.00	9.00~13.00	-
430	≤0.12	≤0.75	≤1.00	≤0.040	≤0.03	16.00~18.00		-
2205	≤0.03	≤1.00	≤2.00	≤0.030	≤0.015	22.00~23.00	4.5~6.5	2.5~3.5
2507	≤0.03	≤0.08	≤1.20	≤0.035	≤0.015	24.00~26.00	6.00~8.00	3.0~5.0
904L	≤0.02	≤1.00	≤2.00	≤0.045	≤0.035	19.00~23.00	23.00~28.00	4.0~5.0		1.0~2.0
INCONEL 028	≤0.03	≤1.00	≤2.50	≤0.030	≤0.030	≤28.0	≤34.0	≤4.0		≤1.4
MONEL 400	≤0.30	≤0.5	≤2.00	-	≤0.024	-	≥63.0	-		≤34.0
INCONEL 800	≤0.10	≤1.00	≤1.50	-	≤0.015	≤23.0	≤35	4.0~5.0	-	≤0.75	Ti≤0.6 Al≤0.6

Packaging & Shipping

Packaging Detail	Each tube is loaded into plastic bag individual, and then several pieces were wrapped in one bundle
Delivery Time	30 days
